Description
Product Description:
- Multiple padlocks can be integrated into the Large Ball Valve Lockout to secure the pipes completely. High-pressure piping systems carrying liquid or gases are secured using it. Due to its ability to accommodate multiple padlocks, several workers can work together to secure the pipes during emergency situations.
- Using padlocks with warning labels is suggested to inform the workers and other personnel that operating or using these energy sources is restricted.
- These types of lockout devices usually come with a two-piece design that holds the pipe in a secure position using the clamping function.
- Adjust the clamp position at the exact point where the handle of the pipe is located and secure it tightly. Large Ball Valve Lockout is compatible with all types of pipe handles, including the ones that are round, square, and flat. Therefore, the workers won’t encounter any issues while installing and removing the lock.
- It helps to maintain OSHA standards during lockout/tagout procedures.
- Large Ball Valve is available in bright colours so that it is easily visible in low-light and dark conditions.
Large Ball Valve Lockout Features
| Key Characteristics | |
|---|---|
| Product Number | |
| Trade Name | Large Ball Valve Lockout |
| Brand Name | KLH |
| Dimensions | |
| Dimensions | 11 in H × 3.8 in W × 7 in D |
| Height | 11 in |
| Depth | 7 in |
| Valve Size Range | 0.5 in |
| Valve Wheel Diameter Range | 1 – 6.5 in |
| Material Characteristics | |
| Material | ABS |
| Color | Red |
| Service Temperature Range °F | 0 °F – 175 °F |
| Product Features | |
| Application | Lockout Tagout |
| Gate Valve Lockout Type | Fits over Handle |
| Maximum Number of Padlock | 4 |
| Risk Type | Mechanical Risk |
| Compatibility | |
| Maximum Handle Thickness | 8 in |
| Maximum Handle Width | 3 in |
| Maximum Shackle Diameter | 0.35 in |
